Description
40m³:
Outside Dimension:4000*4000*2500mm
Inside Dimension:3800*3800*2200mm
Temperature:-18℃
Refrigerant: R404a
Volume:40m³
Voltage:380V/50Hz
Insulation Panel:85.04sq.m/100mm
Compressor:8HP Copeland
Door Size:800*1800mm
Material: Color Steel Plate
Adaptable Condition: Normal Temperature
*Confirm the door position before the order
*Including controller systems, lamp, electromagnetic valve, pipe whole set cooling system
50m³:
Outside Dimension:5000*4000*2500mm
Inside Dimension:4800*3800*2200mm
Temperature:-18℃
Refrigerant: R404a
Volume:50m³
Voltage:380V/50Hz
Insulation Panel:85.04sq.m/100mm
Compressor:8HP Copeland
Door Size:800*1800mm
Material: Color Steel Plate
Adaptable Condition: Normal Temperature
*Confirm the door position before the order
60m³:
Outside Dimension:6000*4000*2500mm
Inside Dimension:5800*3800*2200mm
Temperature:-18℃
Refrigerant: R404a
Volume:60m³
Voltage:380V/50Hz
Insulation Panel:85.04sq.m/100mm
Compressor:10HP EMERSON Copeland
Door Size:800*1800mm
Material: Color Steel Plate
Adaptable Condition: Normal Temperature
*Confirm the door position before the order
*Including controller systems, lamp, electromagnetic valve, pipe whole set cooling system
70m³:
Outside Dimension:5600*5000*2500mm
Inside Dimension:5400*4800*2200mm
Temperature:-18℃
Refrigerant:R404a
Volume:70m³
Voltage:380V/50Hz
Insulation Panel:85.04sq.m/100mm
Compressor:10HP EMERSON Copeland
Door Size:800*1800mm
Material:Color Steel Plate
Adaptable Condition:Normal Temperature
*confirm the door position before order
*Including controller systems, lamp, electromagnetic valve, pipe whole set cooling system
80m³:
Outside Dimension:6400*5000*2500mm
Inside Dimension:6200*4800*2200mm
Temperature:-18℃
Refrigerant:R404a
Volume:80m³
Voltage:380V/50Hz
Insulation Panel:85.04sq.m/100mm
Compressor:12HP Copeland
Door Size:800*1800mm
Material:Color Steel Plate
Adaptable Condition:Normal Temperature
*Confirm the door position before order
*Including controller systems, lamp, electromagnetic valve, pipe whole set cooling system
90m³:Outside Dimension:6000*6000*2500mm
Inside Dimension:5800*5800*2200mm
Temperature:-18℃
Refrigerant:R404a
Volume:90m³
Voltage:380V/50Hz
Insulation Panel:85.04sq.m/100mm
Compressor:15HP EMERSON Copeland
Door Size:800*1800mm
Material:Color Steel Plate
Adaptable Condition:Normal Temperature
*Confirm the door position before order
*Including controller systems, lamp, electromagnetic valve, pipe whole set cooling syste
